MAIN DRIVEWAY (21’4″ x 41′ x 4″): One off-center longitudinal joint and three uneven transverse joints, leaving panels up to 13’3″ x 11’3.5″. Batch tickets show a pea rock mix. Common ACI-based guidance ties joint spacing to slab thickness (roughly 24 to 36 times), with tighter spacing for smaller aggregate and higher-shrinkage mixes. For a 4″ slab, that’s roughly 8 to 10 feet at the tighter end. Palm Bay’s Final Inspection checklist (Section C1) also lists a 10′ maximum for a 4″ slab. In our view, these oversized panels contributed to the centerline and “Y” cracking.
ACCESSORY DRIVEWAY (12′ x 30′ x 4″): No longitudinal joint and two hand-tooled transverse joints. It split along the unjointed centerline. Our time-stamped footage shows a gap of at least 68 minutes between truckloads. The crew tooled the joints on the first section before the last truck began pouring, then raked the new load against the partially set concrete, which we believe broke the slab’s monolithic continuity and created a cold joint failure due to the placement delay. A common argument cites ASTM C94’s 90-minute limit; our understanding is that it governs delivery truck discharge time from the batch plant, not delays between placements.
THE DISPUTE: On August 6, 2026, GHC’s owner emailed us the Cemex rebound hammer report with no other comment or explanation, leaving us with no answers to our technical questions. In our view, they stood on this document as their sole proof, treating a surface hardness test as a complete answer to our joint layout and placement concerns. Some cite ACI guidance for the point that some cracking is normal. We agree; our concern is that joint layout is a main way to control where cracks form.
GHC relied on a rebound hammer report from Cemex, its concrete supplier. Our footage shows GHC and Cemex performing the test together on July 15, 2026. We weren’t told they were coming; we happened to be home. The report lists a test date of August 5, 2026, calculating an age of 826 days to match the day the letter was written. Our concerns:
• Cemex’s letter notes contraction joints are a preventative measure, but the report does not evaluate our joint layout or panel sizes.
• Our footage of the full test shows the hammer used across the driveways on a weathered broom finish. It does not show the surface being ground. ASTM C805 calls for grinding the test surface to prevent distorted or elevated readings.
• Per ASTM C805, this method measures surface hardness only and explicitly states it is not intended as a basis for acceptance or rejection. A surface hardness test can’t answer questions about joint layout or placement.
We weren’t willing to accept cosmetic touch-ups on driveways just over two years old with severe cracking and chunking. We didn’t pay for new driveways to have them patched. Rather than incur more expert costs, we hired a new contractor and are replacing both driveways in phases.
This is our experience and opinion, based on our own measurements, footage, research, and documents.
Questions worth asking any concrete contractor:
1. Will joint layout follow local and ACI 360R spacing guidance for a 4″ slab?
2. If you use pea rock, will you tighten joint spacing?
3. What’s your protocol for delays between truckloads?
4. If a defect is disputed, will testing be handled by an independent, certified lab?
5. Does the contract include a mutual attorney’s-fee clause?
